Rotary dryer

  • Weight:9-135t
  • Capacity:1.9-76t/h
  • Weight:9-95(t)



Rotary dryer has the advantages of large capacity, wide application ranges, small flow resistance, large operation ranges, convenient operation, etc. It is commonly used for drying sand, slag, sludge, coal slime, limestone, quartz stone, granular material, powder material, paste material, compound fertilizer, chicken manure and cow dung.



Rotary dryer is used widely in various industries, and the color and shape of final product is very good. When the dryer is working, it keeps smooth and can dry material very fast, which obtains higher revenue.

60s rapid response

Answer customer questions professionally

Free scheme design

Combined with the actual configuration plan

Perfect Service

Regular return visit and testing

Product details

It can display the temperature on feeding /end site by thermometer ,providing basis for controlling cylinder temperature (350-380 degrees) . Reasonable selection parameters of drying machine, its coal consumption and electricity consumption is less 10-15% than generally drier at least , yield rises over 10-15%, has been widely used in cement and mineral processing enterprises.

Because the different materials have high requirement on the dryer texture , afuruika dryer’s lifter can choose different texture depend on the the different material properties, such as stainless steel, high manganese steel etc.! Drying machine roller made of 45 Cr material and roller adopt 35 CrMo material .It is wear-resistant practical! To the greatest extent to reduce the degree of replacement of wearing parts of the equipment, it brings great benefits to customers later equipment repair and production operation!

Project Introduction

Introduction

Rotary dryer has the advantages of large capacity, wide application ranges, small flow resistance, large operation ranges, convenient operation, etc. It is commonly used for drying sand, slag, sludge, coal slime, limestone, quartz stone, granular material, powder material, paste material, compound fertilizer, chicken manure and cow dung.

Product Advantage

  • High ratio of crushing
  • Even final size, -Simple structure
  • Reliable working condition
  • Easy maintenance
  • Low operating cost

Product display

Technical Parameters

Offering customized solutions and price discounts

ModelCylinder Speed  (r/min)Shell(m³) cubageCapacity (t/h)Gradient  (°)Highest inlet air temperature(℃)Main motor power(kw)Weight   (t)
φ1.2×108--1511.32.4--3.03--5700-8007.511
φ1.5×128--1521.24.5--5.73--5700-8001518.5
φ1.5×158--1525.75.3--6.63--5700-8001519.7
φ1.8×128--1530.56.5--8.13--5700-80018.521.5
φ1.8×168--1536.88.1-10.23--5700-80018.524
φ2.2×148--1553.211.4-14.23--5700-8002236
φ2.2×168--1560.813.0-16.23--5700-8002238
φ2.2×188--1568.413.5-16.93--5700-8002245
φ2.4×186--1081.417.4-21.73--5700-8003749
φ2.4×206--1090.419.3-24.13--5700-8003754
φ2.4×226--1099.521.2-26.53--5700-8003758
φ2.6×206--1010623.2-28.63--5700-8004564
φ2.6×226--1011625.4-31.53--5700-8004567
φ2.6×256--10127.527.4-34.33--5700-8005572
φ2.8×224--813532.8-40.63--5700-8005578
φ2.8×264--816036.0-46.23--5700-8007585
φ2.8×284--817238.4-49.13--5700-8007592
φ3.2×253--620142.9-53.63--5700-8009095
φ3.2×303--621150.6-64.83--5700-800110103
φ3.6×283--628560.8-76.03--5700-800160135
